| Model | UKP-250 | UKP-315 | UKP-400 |
| Number of Poles | 3P / 4P | 3P / 4P | 3P / 4P |
| Rated Current Ie (A) | 125–250 | 275–315 | 250–400 |
| Rated Insulation Voltage Ui / Ue (AC-20 / DC-20) | 1000 V | 1000 V | 1000 V |
| Dielectric Strength (50 Hz / 1 min) | 10 kV | 10 kV | 10 kV |
| Rated Impulse Withstand Voltage | 12 kV | 12 kV | 12 kV |
| Rated Making Capacity (A) | Up to 2500 | Up to 3150 | Up to 4000 |
| Rated Breaking Capacity (A) | Up to 2000 | Up to 2520 | Up to 3200 |
| Rated Short-Time Withstand Current (kA) 1000 V / 0.15 s | 15 | 31 | 31 |
| Rated Short-Time Withstand Current (kA) 1000 V / 0.25 s | 15 | 24 | 24 |
| Rated Short-Time Withstand Current (kA) 1000 V / 1 s | 8 | 15 | 15 |
| Rated Short-Circuit Making Capacity (kA) | 16 | 30 | 30 |
| Operating Torque (N·m) | 7 | 7 | 16 |
UKP-250F11K 2-Pole 250A Front-Handle AC Switch Disconnector for Industrial Control Panels
The KRIPAL UKP-250F11K is a 2-pole, 250A rated AC switch-disconnector engineered for base/screw-mount installation inside electrical enclosures, with the operating handle fitted directly on the front face of the switch body.
Rated for on-load switching up to 250A, it delivers a visible, positive break for safe isolation of single-phase or two-pole circuits. The compact front-handle layout suits shallow panels and small enclosures where side clearance is limited, while a transparent viewing window lets technicians confirm contact position at a glance without opening the enclosure.
Free Quote NowKey Features
- 2-pole configuration, rated current up to 250A (selectable 125–250A range)
- Direct front-panel mounted handle — no linkage or extension rod required
- Base/screw mount for secure fixing inside distribution boards and motor control panels
- Visible contact-position window for quick visual verification
- Spring-stored energy mechanism for quick-make, quick-break operation
- Rated insulation voltage (Ui/Ue) 1000V; suitable for AC-20/DC-20 duty
- High dielectric withstand (10kV/1min) and 12kV impulse withstand rating
- On-load switching capability — safe to operate under normal load conditions
- CE, LVD, CB, SEMKO certified
Application
- Main incoming switch in small distribution boxes and load centers
- Isolation point for lighting or auxiliary circuits in commercial buildings
- Compact motor control panels requiring space-saving front-mounted operation
- Maintenance isolation for two-pole equipment in industrial control cabinets
- Residential/light-commercial sub-distribution enclosures with limited panel depth
